Eco Smartz Automatic Compression Machine (Welded Frame) 5000 kN NL 4000 X / 025

Eco Smartz Automatic Compression Machine (Welded Frame) 5000 kN

Eco Smartz Automatic Compression Machine (Welded Frame) 5000 kN NL 4000 X / 025

Standard: EN 12390-3,-4,-12504-1,1354,1521,13161,1338 772-1, -6, 13286-41 196-1459-2. BS 3892-3, 187

Compression And Flexural

Multi-purpose compression test machine with two compression frames using a single control unit. This machine provides an economic solution to test both concrete & mortar samples without having to purchase two separate machines. Dual channel system enables the calibration to be done independently for each frame. The 500kN frame may also be used as a flexural frame for testing of concrete beams by using the optional flexural
attachment

Technical Specifications:

Model Number	NL 4000 X / 025
Max. Vertical Clearance	435 mm
Max. Horizontal Clearance	580 mm
Capacity	5000 kN x 1.0 & 999kN x 0.1kg Sensitivity
Compression Platen Diameter	300 mm
Piston Ram. Diameter	440 mm
Piston Ram Travel	50 mm
Accuracy	Class 1
Frame Dimension (mm)	750 (L) x 660 (W) x 1500 (H)
Console Dimension (mm)	620 (L) x 500 (W) x 1300 (H)
Approx. Product Weight	2800 kg
Approx. Packing Weight	2950 kg
Power	220 V, 2.5 Amp, 50 / 60 Hz, 1 ph
