PolyAn has developed a range of functionalized sinter materials, fleece and membranes with reactive surfaces as well as inert, permanently hydrophilisized surfaces
| Id |
Title |
Product Dimensions |
| 101 00 011 |
3D-Amino functionalized PP membrane |
80 x 120 mm |
| 101 00 020 |
3D-Amino PE fleece |
80 x 120 mm |
| 101 00 030 |
3D-Amino PE sinter plate |
80 x 120 mm |
| 101 00 106 |
3D-Carboxy functionalized PP membrane |
80 x 120 mm |
| 101 00 117 |
3D-Carboxy PE sinter plate |
80 x 120 mm |
| 101 00 225 |
3D-Epoxy functionalized PP membrane |
80 x 120 mm |
Carriermaterials for the Solid- Phase-Synthesis and Combinatorial Chemistry
Applications of PolyAn's reactive surfaces include:
- Synthesis and spot-synthesis of DNA-Arrays, Peptide-Libraries and Carbohydrate-/Small Molecule-Libraries. The geometry of the sinter materials makes these products especially suitable for small-volume synthesis
- Immobilisation of biomolecules, enzymes, antibodies, targets / API, receptors, ligands, metal complexes, metal ions, e.g. for Flow Chemistry applications.
- Filtration / purification, e.g. as support for scavenger applications
- Line Immuno Assays (LIA) and membranes based microarrays
PolyAn's products which have been specifically developed for the solid phase syntheses and combinatorial chemistry are surface-modified, chemical inert and mechanically robust materials
With our innovative functionalisation-process we are able to anchor a wide range of ligands covalently onto the respective surface without influencing the chemical or biological properties of the ligand. The chemical reactivity (nature and accessibility of the chemical function) has been optimised while the relevant physical properties, e.g. the transport properties in the case of membranes, can be retained
PolyAn's reactive substrates can for example be integrated in microtiterplates or used as reactive media in chemical reactors. It is possible to fit the material into cartridges, columns and filters. The modified surfaces can also be used as Merrifield resins, i.e. the usual instructions and protocols can be easily transferred. All chemical reactions, which are possible with resin/gel-systems, can also be realised with PolyAn's reactive substrates. Contrary to most of the conventional Merrifield resins, the PolyAn's reactive materials do not have to swell in order to achieve the optimal reactivity
If the solid phase synthesis is carried out on larger surfaces, e.g. membranes or plates, it is possible to address defined spots on the surface (→ combinatorial synthesis, production of substance libraries, screening). The synthesised products can be easily punched or cut out for further use. The punched out areas can also be used as micro-reactors
