High optical quality No.1 (0.13 – 0.16 mm, unless different thickness is specified), glass coverslips, suitable for in-vitro diagnostic applications
Select diameter when ordering
These cover glasses meet the requirements of DIN ISO 8255 and are made of pure, perfectly clear and chemical resistant borosilicate glass of the first hydrolytic class (refractive index ne (546.07 nm) = 1.524 to 1.527 / Abbe coefficient ve = 55). Absolutely colorless, perfectly clear, suitable for fluorescence microscopy. Made in Germany.
High precision cover glasses, No 1.5H, CSHP-
Cover glasses for high performance microscopes, made of chemically resistant borosilicate glass of the first hydrolytic class, SCHOTT D 263, with precision thickness No. 1.5 (0.170 mm ± 0.005 mm), suitable for in-vitro diagnostic applications
Absolutely colorless, perfectly clear, suitable for fluorescence microscopy. Made in Germany
For objectives with high numerical aperture and resolution
accurate thickness of 0.170 mm with tolerance reduced to ± 0.005 mm
non-corroding borosilicate glass
refractive index ne: 1.524-1.527 at 546.07 nm
Abbe coefficient: ve=55
recommended for the following objectives:
dry objective: N.A. 0.7
water immersion: N.A. 1.0
glycerol immersion: N.A. 1.2
oil immersion: N.A. 1.3
developed in cooperation with Zeiss and Schott
Hydrophobic cover glasses, No 1, CS-...-H
Made of chemically resistant borosilicate glass of the first hydrolytic class, suitable for in-vitro diagnostic applications. Absolutely transparent, suitable for fluorescence microscopy. With super hydrophobic surfaces on both sides (e.g. for use in crystallography). Thickness No. 1 (0.130 to 0.160 mm). Made in Germany
