zenCELL owl

Live cell imaging with the zenCELL owl incubator microscope enables automatization and parallelization of routine and specific cell culture
applications. zenCELL owl uses 24 independent cameras to acquire brightfield scans and perform image analysis of up to 24 wells of your
cell culture in parallel automatically.
The specialized software provides data visualization and analysis in real time and around the clock – 24/7. Culture quality and data can be comfortably checked from your PC – anywhere and anytime without entering the lab.
The space-saving and easy-to-handle device is compatible with a range of standard cell culture vessels like multi-well plates, flasks or individual formats.

Technical Specifications – zenCELL owl

• Operating System: Windows® 8, 10 (32/64 Bit)
• Processor: 2.5 GHz, 4 cores
• RAM: 8 GB
• Interface (power supply, data transfer): USB 3.0
• Power supply: 5 V
• Protection class: IP62
• Operating temperature: 20 – 45 °C
• Humidity: 20 – 95%
• Compatible with: Isopropanol, Ethanol

• Dimensions (W × H × D): 10.5 × 18 × 18 cm
• Weight: 1050 g

• Light source: LED
• Camera: 5 MP CMOS
• Optical filters: None
• Contrast method: Digital Phase Contrast

• Field of view per microscope: 1.2 mm × 0.9 mm
• Display resolution per microscope: 2592 × 1944
• Image resolution: 5 MP
• Magnification: 10x (+ digital zoom)

• Image capture time: 30 s for 24 wells
• Adjustable recording interval: from 10 minutes to 1 day

• Images: PNG, JPG, BMP
• Video: AVI
• Dataset: CSV

• Cell culture monitoring
• Scratch assay (wound healing)
• Confluence analysis
• Drug treatment studies
