- Holds 1 Syringe up to 140 mL (200 mL partially filled)
- NE-8060: Infusion rates from 6.803 µL/hr (1 mL syringe) to 1021 mL / min (140 mL syringe)
- Easy-to-use keypad interface
- One-click program upload from "Pumping Program Generator" spreadsheet
- Space Saving Chassis: Foot print size of only 11 1/4" x 6 1/8"
- Won't take up unnecessary space on your laboratory or production bench
- Includes all the advanced functions and programming features of the NE-1000 series
Maximum Force: 200 lbs
The NE-8060 produces about 200 lbs of linear force at slow speeds and 100 lbs at top speed. Pressure output is relative to the syringe size
Features of the NE-8000 Series of Syringe Pumps:
- Built-in adjustable and programmable limit switches for infusion and withdrawal
- Adjustable force limit reduces maximum force
- Fully programmable; Designed for automation
- Operates stand-alone or from a computer. Cables sold separately.
- Infusion and withdrawal
- Set a single pumping rate and / or dispensing volume
- Program up to 41 pumping phases that change pumping rates, set dispensing volumes, insert pauses, control and respond to external signals, sound the buzzer
- Network, control, and monitor up to 100 pumps with one computer
- Worldwide power supplies available
- Dispensing accuracy of +/- 1%
- Unlimited lifetime technical support
Not for clinical use on humans
Example Flow Rates NE-8060:
|
Syringe Size
|
Maximum Rate
|
Minimum Rate
|
|
1 µL
|
15.62 mL/min
|
6.777 µL/hr
|
|
3 µL
|
65.89 mL/min
|
28.7 µL/hr
|
|
5 µL
|
109.6 mL/min
|
47.76 µL/hr
|
|
10 µL
|
178.8 mL/min
|
77.89 µL/hr
|
|
20 µL
|
284.4 mL/min
|
123.9 µL/hr
|
|
30 µL
|
371.0 mL/min
|
161.6 µL/hr
|
|
50 µL
|
603.3 mL/min
|
262.7 µL/hr
|
|
140 µL
|
1021 mL/min
|
444.9 µL/hr
|
